K&F Concept Nano-B series variable ND 2-400 filter review 15th Feb 2025 2026
Talk Photography was offered the opportunity to review this filter by K&F Concepts, and we were sent a FOC sample in our choice of thread size by K&F. I’ve been aware of K&F previously, having used their lens adapters previously: they have seemed of good quality and worked well for the task required, so I was happy to take the sample for review.
First impressions
Initial impressions were very good, with a nice quality outer box in an orange metallic finish and inside the filter in a sturdy fitted protective case plus some wipes and a couple of printed sheets. There were no instructions, and presumably if you’re buying this kind of product then you will be familiar with the way to use it, but if I’d just received this as an order then I would be very happy with it.
Construction and fitting
Out of the case, the filter unit looks very nicely made, and feels substantial in the hand. Printed around the upper section on the outside of the ring in addition to the makers name and filter range is the thread size (77mm in this case) plus a Max-Min range with a series of 12 dots that reduce in size, indicating a possible working range for the filter. Turning the upper ring against the inner, the movement is nicely damped and feels very smooth – it would not be easily knocked out of place when handling the camera.
Construction uses “premium Japanese optical glass with nano-coating provides neutral colour balance, reduces lens flare, removes ghosting and better protection against scratches, dirt, and grime”. Nice.
Fitting the filter to a test lens – a Sony 24-105 f4 G series lens – was very easy. The threads seem cut well, and engaged first time and without difficulty. The filter also removed and went back on in field conditions and with cold hands every time, and fitted easily. However at this point I must mention my first niggle with the filter unit, and that is although the top movable ring appears threaded, that thread is larger than the lower thread and it is not possible to fit a lens cap. Also the filter itself is wider than the end of my lens, preventing fitting of the lens hood to stop flare and protect the filter, however that’s not necessarily a problem for a filter that you fit for a specific reason and then remove again.
Principles of operation
How does a variable neutral density filter work? The system consists of two stacked, rotating polarizing filters, and turning the front element changes the angle between them, reducing the amount of light that can pass through, allowing continuous adjustment from near clear to relatively dark (e.g., 2 to 8 stops) without changing filters. This enables control of exposure ‘on the fly’ for example if you wish to retain a shallow depth of field with a wide aperture lens, yet want a longer shutter time and have to work in a bright environment, then this kind of filter is really helpful. As they say, there ain’t no such thing as a free lunch, and this type of filter can cause artifacts like heavy vignetting across parts of the image (sometimes seen as an X pattern of light and dark).
Also common to other types of ND filters, they may cause colour casts to the image and suffer additional flare from the surfaces of the filter glass.
Testing process
The filter as already mentioned, was fitted to a Sony 24-105 G series zoom on my workhorse A7III camera. There were reports that wider angle lenses could make the interference artifacts from this type of filter more obvious, so I was keen to try this at a range of focal lengths. The camera was mounted on a heavy steel tripod with ball head, and steadyshot was turned off throughout testing.
When reviewing the images afterward, the shutter speed, aperture and focal lengths used were noted for evaluation of the results. Images were reviewed ‘straight out of camera’ as ARW files for direct comparison, and where useful, a fixed adjustment was made to all images of the same set.
In use
In many ways the filter works exactly as you would expect, mostly. When in place on my mirrorless A7III and in aperture priority mode with fixed ISO, the camera would always adjust the brightness of the viewfinder to compensate for the strength of the filter, so it didn’t matter whether it was on minimum of maximum because the image on the rear screen always looked the same. What was important was to look at the shutter speed in order to gauge whether it was where it needed to be, and to be sure not to turn the filter too far when seeking a longer exposure.
Now, we need to talk about artifacts
Using the lens on a wide-angle setting, and even zooming in to about 50mm, around the maximum density setting it was possible to cause 2 opposite corners to go very dark and 2 corners light. This was not always immediately obvious if you didn’t know what to look for, and in mild cases, it would be easy to fix in post. Zooming the lens out to 105mm effectively eliminated the artifacts, although turning too far past maximum could make the image lose contrast and look rather grey, however this was obvious on the screen. But I need to emphasis that if the front element of the lens was not turned past the biggest spot on the rim then this was kept under control, and in normal use by someone who knew what they were using, this should never be a problem.
Any other issues?
1) Shooting directly into the sun with it near the middle of the frame cause major flare problems, with green and purple blobs and a bit of a halo, very clear when comparing pictures with and without the filter. However shooting with the sun close to one edge considerably reduced the artifact issue. This was a surprise, but this flaw wouldn’t stop me using the filter.
2) Depending on light direction, the action of the rings wasn’t always consistent, probably because of the way light was striking the first polariser: sometimes turning the front filter would have an immediate effect, sometimes no effect at all until the 4th or 5th spot was reached up from minimum. This is part of the nature of polarisers, and experience would help the effect be managed.
3) The filter is not completely neutral, and produced a variable warm cast, like an old fashioned tobacco filter. The effect was quite pleasing, and could be eliminated easily if shooting raw, but it might be problematic if the colours must be neutral and consistency was required with and without the filter.
OK, that’s the negative – what about the good?
Well first off, the filter appeared not to have any obvious effect on sharpness, and comparing sections of the image at 100% with and without showed no obvious difference. I don’t have test charts, but the images were quite as sharp as when the filter was removed. This is important, and speaks to the quality of the optical materials used, that I could put 2 additional pieces of glass in front of the lens and not see an obvious change, because not all filters are made as well as this.
Next, the filter does what you expect it to – you get what you have paid for. Depending on light direction, the filter itself appeared to absorb between 1.5 and 2.5 stops when set to minimum, with an adjustment range covering around another 4 to 8 stops depending on focal length selected and light direction. To put some context on that in terms of exposure time, without the filter in place, my photograph of Lock Cottage in the distance required 1/125th at f8, but with the filter at maximum I could use a 2.5 second exposure to smooth the water.
The filter doesn’t affect sunstars, if those are something you want. Shooting into the sun at f22 produced very pleasing sunstars typical for the lens, that were unaffected by the presence of the filter.
Conclusions
This is not a filter for someone who doesn’t know how it works and doesn’t want to learn. To get the best from this requires practice and experience. However when used with care, knowledge and intent it can produce some excellent results and works as expected bar the colour shift.
Although I suggested at the beginning that this was not a fit and forget filter because of the issues with a lens hood, it IS a filter that can be mounted and used intentionally all the time because of the excellent optical qualities. This may well find a place in my travel bag.
Link to the actual filter used is here:
www.kentfaith.co.uk
Summary review of photos
Example pictures on next pages.
Please note that these are raw files without adjustment except for the last image in order to show what the filter is capable of producing, rather than to demonstrate how good my processing skills are. The final image has been processed to give an example of what can be achieved.
The waterfall
An obvious use for such a filter to a photographer is to create ‘silky water’ using a longer exposure, so my first stop was at a small local waterfall. In order to get a feel for the filter performance, with the filter fitted and on minimum. ISO was adjusted fixed at 100 and adjustments made from minimum to maximum, giving exposures at 0.15, 0.7sec, 4.0 and 20sec. There was no photo without the filter because the waterfall is enclosed and access to the camera and lens to remove the filter risked dropping it.
At the time of taking, only the maximum effect gave obvious dark corners, but on review the images, it was clear that the adjustment for the 4.0 second exposure also has slightly darkened corners, although they were much less obvious. The image that received a 20 second exposure showed a brighter centre and darker corners due to the interference pattern. There was no obvious loss of sharpness at the different settings.
Waterfall 34mm focal length – 4 seconds – close to max density.Fitting the filter to a test lens – a Sony 24-105 f4 G series lens – was very easy. The threads seem cut well, and engaged first time and without difficulty. The filter also removed and went back on in field conditions and with cold hands every time, and fitted easily. However at this point I must mention my first niggle with the filter unit, and that is although the top movable ring appears threaded, that thread is larger than the lower thread and it is not possible to fit a lens cap. Also the filter itself is wider than the end of my lens, preventing fitting of the lens hood to stop flare and protect the filter, however that’s not necessarily a problem for a filter that you fit for a specific reason and then remove again.
Principles of operation
How does a variable neutral density filter work? The system consists of two stacked, rotating polarizing filters, and turning the front element changes the angle between them, reducing the amount of light that can pass through, allowing continuous adjustment from near clear to relatively dark (e.g., 2 to 8 stops) without changing filters. This enables control of exposure ‘on the fly’ for example if you wish to retain a shallow depth of field with a wide aperture lens, yet want a longer shutter time and have to work in a bright environment, then this kind of filter is really helpful. As they say, there ain’t no such thing as a free lunch, and this type of filter can cause artifacts like heavy vignetting across parts of the image (sometimes seen as an X pattern of light and dark).
Also common to other types of ND filters, they may cause colour casts to the image and suffer additional flare from the surfaces of the filter glass.
Testing process
The filter as already mentioned, was fitted to a Sony 24-105 G series zoom on my workhorse A7III camera. There were reports that wider angle lenses could make the interference artifacts from this type of filter more obvious, so I was keen to try this at a range of focal lengths. The camera was mounted on a heavy steel tripod with ball head, and steadyshot was turned off throughout testing.
When reviewing the images afterward, the shutter speed, aperture and focal lengths used were noted for evaluation of the results. Images were reviewed ‘straight out of camera’ as ARW files for direct comparison, and where useful, a fixed adjustment was made to all images of the same set.
In use
In many ways the filter works exactly as you would expect, mostly. When in place on my mirrorless A7III and in aperture priority mode with fixed ISO, the camera would always adjust the brightness of the viewfinder to compensate for the strength of the filter, so it didn’t matter whether it was on minimum of maximum because the image on the rear screen always looked the same. What was important was to look at the shutter speed in order to gauge whether it was where it needed to be, and to be sure not to turn the filter too far when seeking a longer exposure.
Now, we need to talk about artifacts
Using the lens on a wide-angle setting, and even zooming in to about 50mm, around the maximum density setting it was possible to cause 2 opposite corners to go very dark and 2 corners light. This was not always immediately obvious if you didn’t know what to look for, and in mild cases, it would be easy to fix in post. Zooming the lens out to 105mm effectively eliminated the artifacts, although turning too far past maximum could make the image lose contrast and look rather grey, however this was obvious on the screen. But I need to emphasis that if the front element of the lens was not turned past the biggest spot on the rim then this was kept under control, and in normal use by someone who knew what they were using, this should never be a problem.
Any other issues?
1) Shooting directly into the sun with it near the middle of the frame cause major flare problems, with green and purple blobs and a bit of a halo, very clear when comparing pictures with and without the filter. However shooting with the sun close to one edge considerably reduced the artifact issue. This was a surprise, but this flaw wouldn’t stop me using the filter.
2) Depending on light direction, the action of the rings wasn’t always consistent, probably because of the way light was striking the first polariser: sometimes turning the front filter would have an immediate effect, sometimes no effect at all until the 4th or 5th spot was reached up from minimum. This is part of the nature of polarisers, and experience would help the effect be managed.
3) The filter is not completely neutral, and produced a variable warm cast, like an old fashioned tobacco filter. The effect was quite pleasing, and could be eliminated easily if shooting raw, but it might be problematic if the colours must be neutral and consistency was required with and without the filter.
OK, that’s the negative – what about the good?
Well first off, the filter appeared not to have any obvious effect on sharpness, and comparing sections of the image at 100% with and without showed no obvious difference. I don’t have test charts, but the images were quite as sharp as when the filter was removed. This is important, and speaks to the quality of the optical materials used, that I could put 2 additional pieces of glass in front of the lens and not see an obvious change, because not all filters are made as well as this.
Next, the filter does what you expect it to – you get what you have paid for. Depending on light direction, the filter itself appeared to absorb between 1.5 and 2.5 stops when set to minimum, with an adjustment range covering around another 4 to 8 stops depending on focal length selected and light direction. To put some context on that in terms of exposure time, without the filter in place, my photograph of Lock Cottage in the distance required 1/125th at f8, but with the filter at maximum I could use a 2.5 second exposure to smooth the water.
The filter doesn’t affect sunstars, if those are something you want. Shooting into the sun at f22 produced very pleasing sunstars typical for the lens, that were unaffected by the presence of the filter.
Conclusions
This is not a filter for someone who doesn’t know how it works and doesn’t want to learn. To get the best from this requires practice and experience. However when used with care, knowledge and intent it can produce some excellent results and works as expected bar the colour shift.
Although I suggested at the beginning that this was not a fit and forget filter because of the issues with a lens hood, it IS a filter that can be mounted and used intentionally all the time because of the excellent optical qualities. This may well find a place in my travel bag.
Link to the actual filter used is here:
77Mm Variable Neutral Density Filter Nd2 Nd400 K&F Concept
K&F Concept Photographer'S New Year Wishlist 2022.K&F Kv31 37Mm Nd2 To Nd400 Variable Nd Filter For Video Kit Includes: 37Mm K&F Concept Filter Kit (Nd2 To Nd400) + Lens Cleaning Cloth
www.kentfaith.co.uk
Summary review of photos
Example pictures on next pages.
Please note that these are raw files without adjustment except for the last image in order to show what the filter is capable of producing, rather than to demonstrate how good my processing skills are. The final image has been processed to give an example of what can be achieved.
The waterfall
An obvious use for such a filter to a photographer is to create ‘silky water’ using a longer exposure, so my first stop was at a small local waterfall. In order to get a feel for the filter performance, with the filter fitted and on minimum. ISO was adjusted fixed at 100 and adjustments made from minimum to maximum, giving exposures at 0.15, 0.7sec, 4.0 and 20sec. There was no photo without the filter because the waterfall is enclosed and access to the camera and lens to remove the filter risked dropping it.
At the time of taking, only the maximum effect gave obvious dark corners, but on review the images, it was clear that the adjustment for the 4.0 second exposure also has slightly darkened corners, although they were much less obvious. The image that received a 20 second exposure showed a brighter centre and darker corners due to the interference pattern. There was no obvious loss of sharpness at the different settings.
Waterfall comparison: Minimum 0.17, 0.7, 4, 20 seconds maximum (showing dark corners)
100% closeup centre.
Direct into the sun
Basic settings were 24mm (widest setting) f8, ISO fixed at 100. Starting at minimum density, the filter was turned 3 spots at a time, however for the final exposure the filter had reached the point of interference, causing the darkened corners again. 4 frames were shot using the filter, with exposures 1/750, 1/250/, 1/90, 1/8, and after the filter was removed a final exposure at 1/2000.
These images were slightly post-processed and received the same (manual) adjustment. The sun was close to the centre of the image and flare with the filter shooting directly into the sun is strong, with green spots above and purple below the light source, plus a visible bright circular halo. In the shot without the filter there are signs of slight haloing, but they are mild and easily fixed in post.
Filter minimum 1/750, 1/250, 1/90, 1/18 maximum. 1/2000 without filter.
24mm f8, 1/250. With filter near minimum.
Without filter 1/2000
A second series of images were shot with the sun nearer to the edge of the image. These showed much less flare, and also less warming except at the setting of greatest density.
24mm f8. Filter minimum 1/250, 1/200, 1/160, 1/80, 1/25, 1/13 maximum. 1/800 without filter.
Lock Cottage
Basic settings were 105mm (longest setting) f8, ISO fixed at 100. In order to see if using a telephoto would reduce the darkened corner effect, the lens was zoomed to maximum and the filter adjusted to the greatest density possible. After the filter was adjusted to the maximum spot it was then gradually backed away 2 spots at a time. Exposure times were 30sec, 2.5 sec, 1/5, 1/15, 1/25, 1/40, 1/50, 1/50, then without the filter 1/125
At maximum density the image returned appears slightly decolourised and lacking contrast. The remainder of the shots produced within the working range of the filter did not show the darkened edges seen with wider settings, and were all sharp. As noted above, compared to the image without filter, all images have a strong warm cast.
Lock Cottage
Basic settings were 105mm (longest setting) f8, ISO fixed at 100. In order to see if using a telephoto would reduce the darkened corner effect, the lens was zoomed to maximum and the filter adjusted to the greatest density possible. After the filter was adjusted to the maximum spot it was then gradually backed away 2 spots at a time. Exposure times were 30sec, 2.5 sec, 1/5, 1/15, 1/25, 1/40, 1/50, 1/50, then without the filter 1/125
At maximum density the image returned appears slightly decolourised and lacking contrast. The remainder of the shots produced within the working range of the filter did not show the darkened edges seen with wider settings, and were all sharp. As noted above, compared to the image without filter, all images have a strong warm cast.
105mm Maximum 2.5 seconds
105mm minimum 1/50
105mm no filter 1/125
105mm lens, 2.5 second exposure (above) with post-processing.
All words and pictures copyright Toni Ertl.
105mm no filter 1/125
105mm lens, 2.5 second exposure (above) with post-processing.
All words and pictures copyright Toni Ertl.
